Automatic fiber opening and filling production line 6drag12
Automatic fiber opening and filling production line 6drag12
Main parameters
|
Automatic toy filling machine (ZDWJTC-L6) |
L6/6 to 12: |
|||||
|
Serial number |
Equipment name |
Model specification |
Power |
quantity |
size |
weight |
|
1 |
Automatic cotton feeder |
ZDSM-5510B |
5.17kw |
1 set |
5500*1400*2350mm |
1680kg |
|
2 |
Opener |
KM/S-700x8-1040 |
12.1kw |
1 set |
2300*1500*1400mm |
1360kg |
|
3 |
Connected cotton feeder |
LJSM-350 |
2.2kw |
2 sets |
880*650*1350mm |
86kg |
|
4 |
Smart cotton storage box |
CMX-L8m³ |
3kw |
2 sets |
2500*1300*3100mm |
680kg |
|
5 |
Pneumatic cotton feeder |
QDSM-300A |
2.2kw |
6 sets |
950*600*910mm |
80kg |
|
6 |
Toy cotton filling machine |
CM-2085 |
1.5kw |
12 sets |
2000*850*2050mm |
450kg |
|
7 |
Square pipe |
/ |
/ |
/ |
/ |
/ |
|
8 |
Square pneumatic tee |
/ |
/ |
/ |
/ |
/ |
|
9 |
PLC electric control box |
Design according to actual needs |
||||
Description of the advantages of the fully automatic cotton opening and filling machine
1. Fully automatic operation and one-key start, the working environment is improved, the production efficiency is improved, and the labor is saved.
2. The intelligent operation of the PLC control cabinet reduces the safety risk of the enterprise to the staff operating equipment.
3. Fully automatic operation reduces improper human operation and prolongs the service life of the equipment.
Private customization: According to your on-site working environment and production volume requirements, we can design a production line suitable for you
Product introduction
- Fully Automatic operation,started by one key.Improve the working environment.Plc control system,reduce the woker fault,extend the machine service life.
- High Efficiency,a weight of 100-350kg raw materials can be put on openers’ conveyor belt in one time, can save 2-3 workers.
- Opening effect is good.To use the force generated by long fine-tooth and multi-tooth roller’s reverse operation strengthens the loosening degree, making fiber cotton open to the best effect.After opening,send the fiber into the intelligent hopper.
- Intelligent hopper save raw material,reduce the waste of the source,not pollute the opening fiber. Sending machine,opening machine,conveyor will automatically start one by one when the intelligent hopper is empty,otherwise,it will stop working.
- Simply operation.Firstly open the input button,use pneumatic cotton feeding machine to send the fiber into intelligent hopper,and then shut down the button when the hopper is full.The fiber can be filled into plush toys,cushions,beddings,toy supplies,car accessories and so on.
